Pure Sine Wave Output: Delivers clean and stable pure sine wave power, making it safe for sensitive electronics such as computers, networking equipment, and modern home appliances.
Integrated Solar & AC Charging (MPPT Ready): Built-in MPPT solar charger supports up to 1000W PV input with a wide MPPT voltage range, while also allowing AC charging—ensuring reliable battery charging from multiple energy sources.
Flexible & Intelligent Power Management: Configurable input priority (Solar or AC) via LCD, selectable input voltage ranges, and adjustable charging currents provide maximum flexibility for different installations and load requirements.
Battery Equalization Function to Optimize Battery Performance and Extend Lifecycle
Specification
Rated Output Power (W)
:
10.000W
Battery Nominal DC Voltage
:
48Vdc
Max. PV Input DC Voltage
:
500Vdc
MPPT Voltage Range
:
90~450Vdc; min. 100Vdc without battery.
Max. Charging Current
:
180A
Phase
:
Single phase
Dimension (DxWxH)
:
141 x 322 x 497mm
Net Weight
:
16.3kg
INPUT
:
Voltage
:
230Vac
Selectable Voltage Range
:
170~280Vac (for personal computers); 90~280Vac (for home appliances)
Frequency Range
:
50Hz/60Hz (auto sensing)
OUTPUT
:
Output Power
:
10kVA/10kW
AC Voltage Regulation (Battery Mode)
:
230Vac±5%
Surge Power
:
20kVA
Efficiency (Peak)
:
93%
Transfer Time
:
10ms (for personal computers); 20ms (for home appliances)
Waveform
:
Pure Sine Wave
BATTERY
:
Battery Voltage
:
48Vdc
Floating Charge Voltage
:
54Vdc
Overcharge Protection
:
63Vdc
SOLAR CHARGER & AC CHARGER
:
Solar Charger Type
:
MPPT
Max. PV Array Power
:
14.000W
Max. PV Input Current
:
22A x 2
Max. Solar Charge Current
:
180A
Max. AC Charge Current
:
150A
Communication Interface
:
RS232/RS485(BMS)/WiFi
OPERATING ENVIRONMENT
:
Humidity
:
5% to 95% relative humidity (non-condensing)
Operating Temperature
:
-10°C to 50°C
Storage Temperature
:
-15°C to 60°C
Key Features
Pure Sine Wave Output: Delivers clean and stable pure sine wave power, making it safe for sensitive electronics such as computers, networking equipment, and modern home appliances.
Integrated Solar & AC Charging (MPPT Ready): Built-in MPPT solar charger supports up to 1000W PV input with a wide MPPT voltage range, while also allowing AC charging—ensuring reliable battery charging from multiple energy sources.
Flexible & Intelligent Power Management: Configurable input priority (Solar or AC) via LCD, selectable input voltage ranges, and adjustable charging currents provide maximum flexibility for different installations and load requirements.
Battery Equalization Function to Optimize Battery Performance and Extend Lifecycle
