Pure Sine Wave Output: Delivers clean and stable pure sine wave power, making it safe for sensitive electronics such as computers, networking equipment, and modern home appliances.
Integrated Solar & AC Charging (MPPT Ready): Built-in MPPT solar charger supports up to 1000W PV input with a wide MPPT voltage range, while also allowing AC charging—ensuring reliable battery charging from multiple energy sources.
Flexible & Intelligent Power Management: Configurable input priority (Solar or AC) via LCD, selectable input voltage ranges, and adjustable charging currents provide maximum flexibility for different installations and load requirements.
Reliable Protection & Auto Recovery: Designed with overload, short-circuit, and overcharge protection, plus automatic restart when AC power recovers—ensuring long-term system safety and uninterrupted operation.
Specification
Rated Output Power (W)
:
1000W
Battery Nominal DC Voltage
:
24Vdc
Max. PV Input DC Voltage
:
102Vdc
MPPT Voltage Range
:
30~80Vdc
Max. Charging Current
:
60A
Phase
:
Single phase
Dimension (DxWxH)
:
88 x 225 x 320mm
Net Weight
:
5kg
INPUT
:
Voltage
:
220Vac
Selectable Voltage Range
:
170~280Vac (for personal computers); 90~280Vac (for home appliances)
Frequency Range
:
50Hz/60Hz (auto sensing)
OUTPUT
:
AC Voltage Regulation (Battery Mode)
:
220Vac±5%
Surge Power
:
2000VA
Efficiency (Peak)
:
93%
Transfer Time
:
10ms (for personal computers); 20ms (for home appliances)
Waveform
:
Pure Sine Wave
BATTERY
:
Battery Voltage
:
24Vdc
Floating Charge Voltage
:
27Vdc
Overcharge Protection
:
31Vdc
SOLAR CHARGER & AC CHARGER
:
Solar Charger Type
:
MPPT
Max. PV Array Power
:
1000W
Max. Solar Charge Current
:
40A
Max. AC Charge Current
:
20A
Communication Interface
:
USB/RS232
OPERATING ENVIRONMENT
:
Humidity
:
5% to 95% relative humidity (non-condensing)
Operating Temperature
:
-10°C to 50°C
Storage Temperature
:
-15°C to 60°C
Key Features
Pure Sine Wave Output: Delivers clean and stable pure sine wave power, making it safe for sensitive electronics such as computers, networking equipment, and modern home appliances.
Integrated Solar & AC Charging (MPPT Ready): Built-in MPPT solar charger supports up to 1000W PV input with a wide MPPT voltage range, while also allowing AC charging—ensuring reliable battery charging from multiple energy sources.
Flexible & Intelligent Power Management: Configurable input priority (Solar or AC) via LCD, selectable input voltage ranges, and adjustable charging currents provide maximum flexibility for different installations and load requirements.
Reliable Protection & Auto Recovery: Designed with overload, short-circuit, and overcharge protection, plus automatic restart when AC power recovers—ensuring long-term system safety and uninterrupted operation.
